Hardware and Software Specifications

Resources about Hardware and Software specifications of Eagle’s streaming servers.

Our streaming servers are located in the central region of southern US Mainland in Texas (we also have the option to use public servers GCP; Azure; AWS etc ..)

Refer to this document to see our Cloud VM Hardware Specifications.

Here are UE specifications that Eagle recommends to make sure that your App performs appropriately in the cloud :

Resource Specifications

Eagle 3D Streaming Hardware for Streaming Unreal Engine Applications :

• 32GB RAM

• 8GB/ 16 GB GPU RAM

• i7/R7 Processor

• RTX 3070/4080 GPU

Preferred Maximum Resource Allocations for Unreal Engine Application :

• CPU utilization: 50-70%

• RAM (Memory): 6GB

• GPU utilization: 50-70%

• GPU VRAM: 4-6GB

Performance Specifications

Additionally, these are the guidelines Eagle recommends :

1. 1280 x 720 resolution;

2. 30 frames per second;

3. No use of PAK files (see below image).

Bandwidth requirements

Note 1:

Download speed of 10 mbps or higher for HD streaming 720p (1280 x 720).

Download speed of 20 mbps or higher for :

• Full HD streaming 1080p (1920 x 1080)

• HD+ (1600 × 900) a step up from 720p (HD Ready) but falls short of Full HD (1080p).

• 2k (2048 × 1080) or (2048 × 1536) used in digital cinema and some professional displays

• 4k Quad HD (QHD) (3840 × 2160) (UHD-1)

Note 2 :

(1080x1920) : Common resolution used for portrait mode on mobile devices.

9:16 aspect ratio.

To enable the Custom Resolution from the Control Panel :

Refer to this document to enable it from the Old Control Panel.

Refer to this document to enable it from the New Control Panel.
