Eagle Pixel Streaming Analytics API

This guide explains how to retrieve streaming session analytics using Eagle’s Analytics API. Use this API to:

Monitor overall streaming activity
Retrieve session-level analytics
Analyze streaming usage over a selected date range

Endpoint

JavaScript

POST https://agw.eagle3dtreaming.com/api/v4/fb/user-data-by-range

Request Body

Send a JSON object in the following format:

JavaScript

{
"start": "YYYY-MM-DDTHH:mm:ss.sssZ",
"end": "YYYY-MM-DDTHH:mm:ss.sssZ",
"apiKey": "YOUR_PERSONAL_API_KEY",
"uid": "YOUR_ASSIGNED_UID"
}

Request Parameters

Parameter	Type	Required	Description
`start`	String	Yes	Start of the analytics range, as an ISO 8601 UTC timestamp (e.g. 2026-06-01T00:00:00.000Z ).
`end`	String	Yes	End of the analytics range, as an ISO 8601 UTC timestamp (e.g. 2026-06-15T00:00:00.000Z ).
`apiKey`	String	Yes	Your personal Eagle API key. Retrieve your API key
`uid`	String	Yes	Your unique Eagle user identifier (UID). Contact Support Team if you do not have your UID.

Example Request Body

JavaScript

{
"start": "2025-04-01T00:00:00.000Z",
"end": "2025-04-10T00:00:00.000Z",
"apiKey": "abc123xyz456",
"uid": "btl6CxobgXRgrbiednegoin2289357gdfkKJBFB"
}

Node.js Example

The following example demonstrates how to call the Analytics API using Node.js and Axios.

Replace the uid and apiKey values with your own credentials before running the script.

JavaScript

const axios = require("axios");

const API_URL =
    "https://agw.eagle3dstreaming.com/api/v4/fb/user-data-by-range";

const getUserDataByRange = async (uid, start, end, apiKey) => {
    try {
        const response = await axios.post(
            API_URL,
            {
                uid,
                start,
                end,
                apiKey,
            },
            {
                headers: {
                    "Content-Type": "application/json",
                },
            }
        );

        return response.data;
    } catch (error) {
        console.error(
            "API Error:",
            error.response?.data || error.message
        );
        throw error;
    }
};

const uid = "YOUR_UID";
const start = "2026-06-01T00:00:00.000Z";
const end = "2026-06-15T00:00:00.000Z";
const apiKey = "YOUR_API_KEY";

(async () => {
    try {
        const data = await getUserDataByRange(uid, start, end, apiKey);
        console.dir(data, { depth: null, colors: true });
    } catch (error) {
        console.error("Status:", error.response?.status);
        console.error("API Error:", error.response?.data || error.message);
    }
})();

Example Response

A successful request returns a response similar to the following:

JavaScript

{
  "data": {
    "count": 138,
    "streamedMinutes": 515.45,
    "data": [
      {
        "appName": "DemoAppTP",
        "appVersion": "3",
        "city": "Texas",
        "country": "USA",
        "videoStartTime": "Mon, 01 Jun 2026 06:10:04 GMT",
        "videoStopTime": "Mon, 01 Jun 2026 06:11:04 GMT",
        "streamTime": 1
      },
      {
        "appName": "DemoAppTP",
        "appVersion": "3",
        "city": "London",
        "country": "UK",
        "videoStartTime": "Tue, 02 Jun 2026 05:34:14 GMT",
        "videoStopTime": "Tue, 02 Jun 2026 05:35:44 GMT",
        "streamTime": 1.5
      }
    ]
  }
}

Response Structure

Top-Level Response

Field	Type	Description
`count`	Integer	Total number of streaming sessions found within the selected date range.
`streamedMinutes`	Number	Total streaming minutes across all sessions.
`data`	Array	List of streaming session records.

Session Object

Each object inside the data array contains the following fields:

Field	Type	Description
`appName`	String	Name of the streamed application.
`appVersion`	String	Version of the streamed application.
`city`	String	User's city.
`country`	String	User's country.
`videoStartTime`	String	UTC timestamp when the streaming session started.
`videoStopTime`	String	UTC timestamp when the streaming session ended.
`streamTime`	Number	Total duration of the streaming session in minutes.

Notes

The API returns streaming analytics across all of your applications within the selected date range.
Filtering by a specific application is not supported in the request. If you need analytics for a single application, filter the returned data using the appName field.
Analytics data typically appears 30 seconds to 1 minute after a streaming session occurs.
Monitor your streaming usage through the Analytics section in the Control Panel.

Swagger API Reference

You can explore and test the API using the Swagger UI

https://agw.eaglepixelstreaming.com/api-docs/

Limitations

Please read the following before integrating this API into your application.

Limitation	Details
Rate Limits	API requests are rate limited. If the limit is exceeded, additional requests may be temporarily rejected until the rate limit window resets.
Not Intended for Real-Time Dashboards	This API is designed for reporting and analytics, not for powering live or real-time dashboards. Avoid high-frequency polling.
Processing Time	Each request requires significant processing on Eagle's infrastructure. Please avoid unnecessary or repeated requests.
Data Delay	Streaming analytics may take 30 seconds to 1 minute to appear after a session begins or ends. Do not rely on the API for instant updates.
No App-Level Filtering	The API returns analytics for all of your applications within the requested date range. Filter the results by the `appName` field on your side if you need data for a specific application.
Date Range Required	Every request must include both the `start` and `end` date parameters. Requests without a valid date range are not supported.

Recommendation

For the most accurate and up-to-date view of your streaming activity, use the monitoring tools available directly in your Control Panel Analytics at https://controlpanel.eagle3dstreaming.com/analytics

Troubleshooting

Issue	Possible Cause	Solution
401 Unauthorized	Invalid or expired `apiKey` Invalid or missing `uid`	Verify that you are using your correct API key. Ensure you are using the correct UID assigned to your Eagle account. Contact Support if you do not have it.
Bad Request	Missing or invalid request parameters	Verify that `start`, `end`, `uid`, and `apiKey` are included and correctly formatted.
No data returned	No streaming sessions exist within the selected date range	Check the selected date range and confirm that streaming activity occurred during that period.
Recent sessions are missing	Analytics processing delay	Wait 30 seconds to 1 minute before requesting the latest analytics again.
Too Many Requests	Rate limit exceeded	Reduce the request frequency and wait until the rate limit window resets before retrying.
Connection or timeout errors	Temporary network issue or server unavailable	Check your internet connection and retry after a short delay. If the issue persists, contact Eagle Support.
